PTFE Teflon Tabber String Belts

Brand: WELLFLON
Materials: PTFE (Teflon), Fiberglass Fabric,Kevlar
Yarn Type: Filament Yarn/Texturized Yarn
Width Range: 1000~4000mm
Features: Non-stick, High-Temp Resistant
Temp. Resistance: -70°C to +280°C
Color: Brow/Black/White /Custom Color
Certification: FDA/LFGB/SGS/RoHS/UL

Our company's PTFE Teflon Tabber String Belts include double-layer compound 4-row stringer belts, 6-row stringer sawtooth joint composite belts, rough breathable tooth-joint perforated stringer belts, solar cell stringer belts, etc. Various specifications and models of belts.
The CHANGWEI seamless stringer belt is made of military Kevlar (aramid fiber) or imported high-strength glass fiber yarn, which is woven into tubular fabric by circular knitting equipment and coated with Teflon emulsion. The interface of the conveyor belt is not easy to break, and the circumference of the joint has good running stability and no deviation. The belt without interface has a service life more than 3 times longer than other types of stringer belts. The stringer belt produced by our company has high straightness and flatness, high hole position accuracy, low elongation, small thermal deformation, high temperature resistance and fatigue resistance.

Main features of PTFE Teflon Tabber String Belts:
The double-layer composite stringer belt is made of high-strength glass fiber yarn or Kevlar (aramid) woven into glass fiber cloth or Kevlar cloth, and is made of Teflon resin (PTFE) impregnated with unique technology. The joint is flat, the walking stability is good, and it is not easy to deviate. The belt interface of the double-layer composite stringer welder adopts a unique toothed connection, which more effectively enhances the strength of the conveyor belt. At present, the inner layer of the double-layer composite stringer welder belt we made is black Teflon high-temperature resistant cloth. The outer layer is brown Teflon high-temperature cloth into high-temperature hot-pressed molding, and then through the punching equipment imported from abroad to carry out precise drilling, the stringer belt produced by our company is also used in the stringer of foreign solar cells On equipment, such as Meyer Burger's somont, Spain's GOROASBEL and other automatic silicon wafer stringers
At present, most large-scale solar cell manufacturers in China import advanced automatic stringers from Europe and America (such as Spanish stringers), and the perforated conveyor belts are also completely dependent on imports. The cost is high and the cycle is long, and they cannot meet customer needs in the first time. After more than a year of hard work, our company has successfully developed a Teflon stringer belt for solar silicon wafer automatic stringer machines in the United Nations.

The main features of PTFE Teflon Tabber String Belts:

High straightness and flatness, high hole position accuracy, low elongation, small thermal deformation, high temperature resistance and fatigue resistance. We can customize according to the samples and drawings provided by customers.
Friendly reminder: Since each customer's stringer belt requirements are different, we need to open a mold before drilling, so the first delivery time is a bit long, if you need it urgently, please order it in advance to avoid delays your production progress.

Main Specifications of PTFE Teflon Tabber String Belts:

Item	Color	Thickness	Max Width	Weight	Tensile Strength	Temperature
CWF-T0158	Brown/Black/White	0.08mm	1250mm	158±5g/m2	500/480N/50mm	-70~280 ℃
CWF-T0160	Brown/Black/White	0.08mm	1250mm	160±5 g/m 2	620/460N/50mm	-70~280 ℃
CWF-T0180	Brown/Black/White	0.08mm	1250mm	180±5 g/m 2	930/720N/50mm	-70~280 ℃
CWF-T0260	Brown/Black/White	0.13mm	1250mm	260±5 g/m 2	100/1000N/50mm	-70~280 ℃
CWF-T0275	Brown/Black/White	0.13mm	1250mm	275±5 g/m 2	1000/960N/50mm	-70~280 ℃
CWF-T0290	Brown/Black/White	0.13mm	1250mm	290±5 g/m 2	910/880N/50mm	-70~280 ℃
CWF-T0395	Brown/Black/White	0.18mm	1250mm	395±5g/m 2	1600/1600N/50mm	-70~280 ℃
CWF-T0415	Brown/Black/White	0.18mm	1250mm	415±5 g/m 2	1500/1500N/50mm	-70~280 ℃
CWF-T0490	Brown/Black/White	0.25mm	2800mm	490±5 g/m 2	2100/1800N/50mm	-70~280 ℃
CWF-T0510	Brown/Black/White	0.25mm	2800mm	510±5 g/m 2	2800/2700N/50mm	-70~280 ℃
CWF-T0660	Brown/Black/White	0.35mm	3200mm	660±5 g/m 2	2700/2600N/50mm	-70~280 ℃
CWF-T0680	Brown/Black/White	0.35mm	3200mm	680±5 g/m 2	2100/2200N/50mm	-70~280 ℃
CWF-T0780	Brown/Black/White	0.40mm	3500mm	780±5 g/m 2	2900/3100N/50mm	-70~280 ℃
CWF-T0820	Brown/Black/White	0.40mm	3500mm	820±5 g/m 2	3000/2900N/50mm	-70~280 ℃
CWF-T1150	Brown/Black/White	0.65mm	4000mm	1150±5 g/m 2	4200/4000N/50mm	-70~280 ℃
CWF-T1550	Brown/Black/White	0.90mm	4000mm	1550±5 g/m 2	6300/5800N/50mm	-70~280 ℃
CWF-T1650	Brown/Black/White	0.90mm	4000mm	1650±5 g/m 2	6150/5300N/50mm	-70~280 ℃

Related Certificates of PTFE Teflon Tabber String Belts:

Our brand WELLFLON ® mainly focus on the field of industrial coatings, the main products are PTFE Teflon coated fiberglass fabrics, PTFE Teflon adhesive tapes, PTFE Teflon conveyor belts, PTFE Teflon seamless belts and so on. The Brand COOKAFLON ® positions in civilian field of non-stick cookware and barbecue utensils,Such as PTFE Teflon Non-stick Baking or Grilling liners,Meshes, Bags, Baskets, etc. If you have any requests, please contact us without hesitation!
