WellFlon® PTFE Teflon Film Adhesive Tape is a PTFE Teflon film tape made of selected high-quality PTFE film as the tape base material, after special surface treatment, and coated with high heat-resistant silicone adhesive on one side. The film tape has high-quality electrical properties, high temperature resistance, corrosion resistance, and anti-adhesive surface.
Main Features of PTFE Teflon Film Adhesive Tape:
● The non-adhesive surface has the good characteristics of many polytetrafluoroethylene resins such as electrical properties, heat resistance, weather resistance, chemical resistance, water resistance (water resistance), and non-adhesiveness;
● Super tensile strength;
● Good fire and flame retardant properties;
● It can be used in the temperature range of -60℃~-260℃, which can be changed according to the use environment.
Main Application of PTFE Teflon Film Adhesive Tape:
● Roll wrapping for polyethylene laminator;
● Endless belts for polyethylene laminator;
● Used as class H insulator for coil insulation
● Can be used as a general smooth material, paste metal, plastic, ceramics and other materials.
Main Specifications of PTFE Teflon Film Adhesive Tape:
| Item | Thickness | Elongation Rate | Surface Resistance | Adhesive Strength | Tensile Strength | Temperature |
| To Steel (N/4cm) | (N/100mm) | |||||
| CWT-PA006 | 0.06mm | 100% | 10¹⁶Ω | ≥ 10 | 300 | -70~260 ℃ |
| CWT-PA008 | 0.08mm | 100% | 10¹⁶Ω | ≥ 12 | 320 | -70~260 ℃ |
| CWT-PA011 | 0.11mm | 100% | 10¹⁶Ω | ≥ 15 | 350 | -70~260 ℃ |
| CWT-PA013 | 0.13mm | 100% | 10¹⁶Ω | ≥ 18 | 400 | -70~260 ℃ |
| CWT-PA018 | 0.18mm | 100% | 10¹⁶Ω | ≥ 20 | 650 | -70~260 ℃ |
| CWT-PA025 | 0.25mm | 100% | 10¹⁶Ω | ≥ 25 | 950 | -70~260 ℃ |
| CWT-PA030 | 0.30mm | 100% | 10¹⁶Ω | ≥ 28 | 1050 | -70~260 ℃ |
*If there are special specifications, our company can offer customize service.
