Fusing/ Laminating Machines

Fusing process is a important method of fabric joining in apparel manufacturing, this process is used to attach the interlining of shirt or outwear. By melting the resin coating of interlining into fabric under heat pressure, both fabric and interlining will be attached strongly when it becomes cool and hard.

For the fusing machines, every operators are allocated to the PTFE Endless Belt, this no joint Teflon conveyor belts allows exact positioning of the parts. Fusing machines are also used in the furniture and automotive industry for applying knitted spacer, foams or non-woven fabrics to leather.

PTFE Endless Belt

PTFE Endless Belt is using high tensile fiberglass or Kevlar as basic material (has no joint), this endless belt is woven by special weaving equipment and coated with high quality Teflon.

Compared with the PTFE belt with joints, it overcomes the phenomenon of easy fracture at the interface joint of the conveyor belt in the past and has better bending fatigue resistance and durability.

Standard length is as follows:

(Surface : Normal or Anti-static)

Standard thickness fabric 14.0~16.0 /mil 0.35~0.40(mm)
Max Width 20/ in 1600 (mm)
Seamlessor Jointless Girth Belt (mm)
1360	1380	1440	1470	1510	1520	1530	1540	1550	1560
1580	1600	1640	1660	1680	1730	1740	1780	1820	1830
1840	1850	1870	1880	1950	2000	2040	2100	2230	2240
2250	2310	2320	2420	2440	2450	2500	2600	2630	2750
2800	2820	2850	2880	2900	3050	3080	3090	3200	3450
3540	3590	3820	3850	3890	3900	3920	3930	4200	4270
5100	5270	5400	5640	5800	6000	6440	6700	6900	7300
8000	8500	8700	9000	9600	10000	11000	18000	12000	12700

PTFE Belt with Joint

PTFE belt with joint for fusing machine is using 0.40mm thick Anti-static PTFE fabric as belt material, and make Butt, finger or overlap joint.

This belt is cost effective and can be made into large belt greater than 6700mm long, but the belt material must has high mechanical strength since the fusing machine is continuous running, and the surface must without any defect in order to ensure the quality of product.

We are commit ourselves to manufacture long lasting and high performance PTFE coated fabric.
